1FG1602-5RC26-2HU1-Z D13+K08

The SIMOTICS S-1FG1 is a synchronous servo geared motor, engineered for precision and reliability in demanding applications. This particular model features a helical worm gear unit C39A, optimized for efficient power transmission. The motor type CT is designed to operate at 600V AH36, ensuring compatibility with various industrial power systems. It delivers a maximum torque (Mmax) of 4.5 Nm and a nominal power (Pn) of 0.41 kW, making it suitable for applications requiring moderate power output. The hollow shaft with keyway H25x120 facilitates easy integration into existing mechanical systems. An absolute encoder with 20-bit single-turn and 12-bit multi-turn resolution, coupled with a DRIVE-CLiQ interface, provides accurate position feedback and control. The housing flange ensures robust mounting, while the gear ratio of 49.87 allows for precise speed reduction. With a maximum input speed (N1MAX) of 4500 RPM and a maximum output speed (N2MAX) of 90 RPM, it delivers a maximum output torque (M2MAX) of 250 Nm.
