1FT7082-5AC74-1NA0 SIEMENS

SKU: 1FT70825AC741NA0
$46,746.00
IN STOCK
Express delivery
New - 12 Months warranty
Delivery: Ships within 3 business days
Worldwide delivery by DHL Express courier
Shipping: Calculated at Checkout
Weight: 15.50 KGS
Width: 25.00 (cm)
Height: 25.00 (cm)
Depth: 50.00 (cm)
HS Code / Commodity code: 85015220
Adding to cart… The item has been added
Description
The SIMOTICS S 1FT7082-5AC74-1NA0 is a synchronous motor designed for high-performance applications. It delivers a stall torque (M0) of 13Nm at 100K and a rated speed (NN) of 2000rpm. The motor's rated power (PN) is 2.39kW, making it suitable for a variety of industrial tasks. This motor is naturally cooled, ensuring efficient thermal management without the need for external cooling systems. It features a frame size compatible with IMB 5 (IM V1, IM V3) mounting configurations and a conventional flange, ensuring compatibility with 1FT6/1FK7 series motors. The integrated Pt1000 temperature sensor provides accurate temperature monitoring for enhanced motor protection. An incremental encoder SIN/COS 1VSS with 2048 S/R (ENCODER I-2048) offers precise position feedback. The motor includes a rotatable power connector and a rotatable connector for the encoder, both with fitted keys. It is manufactured with accuracy tolerance N, without a holding brake, and complies with vibration severity grade A and IP 64 degree of protection.
