1PH7105-2NF02-0CJ0 SIEMENS - REF

SKU: 1PH71052NF020CJ0
$30,528.00
IN STOCK
Express delivery
Refurbished - 6 Months warranty
Delivery: Ships within 3 business days
Worldwide delivery by DHL Express courier
Shipping: Calculated at Checkout
Weight: 55.00 KGS
Width: 40.00 (cm)
Height: 40.00 (cm)
Depth: 60.00 (cm)
HS Code / Commodity code: 85015220
Adding to cart… The item has been added
Description
The SIMOTICS M compact asynchronous motor 1PH7105-2NF02-0CJ0 from Siemens is a high-performance motor designed for demanding industrial applications. It delivers a rated power of 7 kW at 1500 rpm, producing a torque of 44.6 Nm. In variable speed control (VC) mode, it achieves 8 kW at 1750 rpm with a torque of 43.7 Nm. The motor operates at 400V 3AC 50Hz and draws 17.5 A. This model is equipped with a relative motor encoder 1 VSS 2048 P/U for precise speed and position feedback. It features a terminal box on top with cable entry on the right side, and its construction type is IM B5 (IM V1, IM V3). The motor has vibration severity level S and shaft and flange accuracy R, with a smooth shaft without a fitted key. Airflow is directed from the drive end (DE) to the non-drive end (NDE). It is protected to IP55, with the fan having IP54 protection, and comes unpainted.
