1PH7167-7FG33-0WK3 SIEMENS

The SIMOTICS M compact asynchronous motor 1PH7167-7FG33-0WK3 from Siemens is a high-performance motor designed for demanding industrial applications. It delivers a continuous power output of 41 kW at 2000 rpm, producing a torque of 195.8 Nm. For variable speed control applications, it can achieve 44 kW at 2300 rpm with a torque of 182.7 Nm. The motor is designed for operation with a 400 V 3AC, 50 Hz power supply and draws 89 A in continuous operation and 88 A in variable speed control mode. It features an absolute motor encoder with a 1 VSS 2048 P/U resolution and a DRIVE-CLiQ interface for precise control and feedback. The motor is constructed in an IM B35 configuration (IM V15, IM V36) with a terminal box located on top and cable entry on the left. A customer-specific bearing version with wide bearings ensures enhanced durability and smooth operation, coupled with a plain shaft without a feather key. The motor's cooling system directs airflow from the non-drive end (NDE) to the drive end (DE), and it is protected to IP55 standards, with the fan meeting IP54 standards. Finished with a standard paint in RAL 7016, this customer-specific version offers robust performance and reliability in challenging environments.
