1PH8163-1HF00-2GA2 SIEMENS

The SIMOTICS M compact asynchronous motor 1PH8163-1HF00-2GA2 from Siemens is a high-performance electric motor designed for demanding industrial applications. It operates at a synchronous speed of 1500 r/min, delivering a power output of 30 kW and a torque of 191 Nm, with a current draw of 71 A at 319 V. The motor can also operate at 1750 r/min, 2000 r/min and 2200 r/min with corresponding power, torque, current and voltage ratings. It features forced ventilation with a defined air flow direction from the drive end (DE) to the non-drive end (NDE), ensuring optimal thermal management. The motor is protected to IP55 standards, providing robust protection against dust and water ingress. An incremental encoder HTL 1024 S/R is integrated for precise position and speed feedback. A Pt1000 temperature sensor is included for monitoring the motor's internal temperature, preventing overheating and ensuring longevity. The motor is designed in IM B3 configuration (also compatible with IM V5 and IM V6 mounting), featuring a shaft with a fitted key and half-key balancing. Standard bearings are used, and the motor adheres to vibration severity grade R/A, with shaft and flange accuracy to grade R. The terminal box is located above, with cable entry on the right side, and signal connections are provided on the drive end.
