1PH8165-1DF00-1FA1 SIEMENS

The SIMOTICS M compact asynchronous motor 1PH8165-1DF00-1FA1 is a high-performance electric motor designed for demanding industrial applications. It delivers a rated power of 37 kW at 1500 rpm, producing a torque of 236 Nm with a current draw of 78 A at 350 V. The motor's versatile design allows for operation at various speeds and power outputs, including 41 kW at 1750 rpm (400 V), 45 kW at 2000 rpm (440 V), and 49.5 kW at 2200 rpm (493 V). Equipped with forced ventilation, ensuring optimal thermal management and reliable performance even under heavy loads. The motor features an IP55 degree of protection, safeguarding it against dust and water ingress. An incremental encoder with 22-bit resolution and commutation position (IC22DQ) is integrated, utilizing a DRIVE-CLiQ interface for precise control and feedback. The motor boasts a robust mechanical design in IM B3 (IM V5, IM V6) configuration, featuring a shaft with a fitted key and full-key balancing. Enhanced bearing design accommodates increased radial forces, and vibration severity is graded at R/A, with shaft and flange accuracy at R. The terminal box is located above, with cable entry on the right side and signal connection at the D-end.
