1PH8186-1DD00-2FB1-Z L27 SIEMENS

The SIMOTICS M compact asynchronous motor 1PH8186-1DD00-2FB1-Z L27 from Siemens is a high-performance motor designed for demanding industrial applications. It operates at 1000 r/min, delivering 51 kW of power and 487 Nm of torque with a current of 112 A at 340 V. Additionally, it can operate at 1150 r/min, providing 58 kW of power and 482 Nm of torque with a current of 112 A at 390 V. Furthermore, it is capable of running at 1350 r/min, producing 67 kW of power and 474 Nm of torque with a current of 112 A at 450 V. The motor features forced ventilation with a defined direction of air flow from the drive end (DE) to the non-drive end (NDE) and boasts an IP55 degree of protection for robust performance in various environments. An incremental encoder with 22-bit resolution and commutation position (encoder IC22DQ) is integrated, utilizing a DRIVE-CLiQ interface for precise control and feedback. The motor is designed in IM B3 configuration (also compatible with IMB6, IMB7, IMB8, and IMV6 mounting options) and includes a shaft with a fitted key and half-key balancing. It is equipped with bearings designed to withstand greater cantilever forces, features vibration severity grade R/A, and has shaft and flange accuracy grade R. The terminal box is positioned above, with the cable entry located on the left side and the signal connection on the D-end.
