3SE5114-0QV10-1AE3 SIEMENS

The 3SE5114-0QV10-1AE3 is a safety position switch designed to monitor the position of moving parts in machinery and equipment, ensuring safe operation. It features a robust metal enclosure with a 40mm width, providing durability in industrial environments. The switch is equipped with an M12 connector, utilizing a 5-pole plastic configuration for reliable electrical connections. It is rated for a maximum of 125V and 4A, suitable for various safety-related applications. The switch supports five different directions of approach, offering flexibility in installation and actuation. It incorporates slow-action contacts with 2 normally closed (NC) circuits, enhancing safety by providing a delayed response. The pin assignments are as follows: Pin1=21, Pin4=22, Pin2=31, and Pin5=32, with Pin3 designated for protective earth (PE). This switch is compatible with all SIMATIC ET200* compact block I/O modules, simplifying integration into existing automation systems. Please note that the separate actuator, specifically the 3SE5000-0AV../W.. series, must be ordered separately to complete the functional assembly.
