4AP2542-8BC40-0HC0 SIEMENS

SKU: 4AP25428BC400HC0
$14,729.76
IN STOCK
Express delivery
New - 12 Months warranty
Delivery: Ships within 3 business days
Worldwide delivery by DHL Express courier
Shipping: Calculated at Checkout
Weight: 15.50 KGS
Width: 20.00 (cm)
Height: 25.00 (cm)
Depth: 30.00 (cm)
HS Code / Commodity code: 85043200
Adding to cart… The item has been added
Description
The 4AP2542-8BC40-0HC0 is a SITAS three-phase transformer designed for control and isolation applications. It features a primary voltage configuration of Y500-400/D289-230V and a secondary voltage configuration of Y 400 / D 230V. The transformer's rated power is 1.4 kVA for continuous operation and 6.9 kVA for short-time duty (S6). The secondary current is rated at 2-3.48A. It is suitable for operation at frequencies of 50 to 60 Hz. The vector group and shield winding configuration is IIIIII0 / 0. The transformer is designed for an ambient temperature of up to 40°C and insulation class B. It has an IP23 protection rating and utilizes screw/tab connections for terminals. Compliant with EN 61558-2-1, -2-2, and -2-4 standards, it is also UL/CSA-recognized.
