6SL3210-1PE18-0UL1 SIEMENS

The Sinamics POWER Module PM240-2 (6SL3210-1PE18-0UL1) is an unfiltered power module with an integrated braking chopper, designed for three-phase AC line voltages ranging from 380V to 480V (+10/-10%) at 47-63Hz. This module is engineered to deliver high performance in demanding industrial applications. It offers two overload modes: a high overload mode delivering 2.2kW for 200% current for 3 seconds, 150% for 57 seconds, and 100% for 240 seconds, suitable for ambient temperatures between -10 to +50 degrees Celsius. Alternatively, a low overload mode provides 3kW at 150% for 3 seconds, 110% for 57 seconds, and 100% for 240 seconds, optimized for ambient temperatures from -10 to +40 degrees Celsius. The module's compact FSA frame size measures 196mm in height, 73mm in width, and 165mm in depth. It features an IP20 protection rating, ensuring safety and reliability in industrial environments. Notably, this power module is designed without a control unit and panel, offering flexibility in system configuration. It is specifically approved for use with CU firmware version V4.6, ensuring compatibility and optimal performance. This module is ideal for applications requiring dynamic braking and precise motor control.
