6SL3211-1PE18-0AL1 SIEMENS

The Siemens Sinamics POWER Module PM240-2 (6SL3211-1PE18-0AL1) is a highly integrated and efficient power module designed for controlling three-phase AC motors. It features a built-in Class A filter, effectively reducing electromagnetic interference and ensuring compliance with EMC standards. An integrated braking chopper allows for dynamic braking of the motor, enhancing safety and performance. This module supports a wide input voltage range of 380-480V AC (+10/-10%) at 47-63Hz, making it suitable for various industrial power grids. For high overload applications, it delivers 2.2kW for 200% overload for 3 seconds, 150% for 57 seconds, and 100% for 240 seconds, within an ambient temperature range of -10 to +50 degrees Celsius. In low overload scenarios, it provides 3kW for 150% overload for 3 seconds, 110% for 57 seconds, and 100% for 240 seconds, with an ambient temperature range of -10 to +40 degrees Celsius. The module's compact dimensions of 238 x 126 x 171 mm (Height x Width x Depth) in Frame Size A (FSA) facilitate easy integration into control cabinets. It offers IP20 protection, safeguarding against solid objects, and requires a separate Control Unit and Panel for operation. This power module is approved for use with CU firmware version V4.6.
