6SL3225-0BH31-5AA1 SIEMENS - REF

The SINAMICS G120 Power Module PM260 (6SL3225-0BH31-5AA1) from Siemens is a robust and versatile drive component designed for controlling three-phase AC motors. It features a built-in Class A filter, ensuring compliance with electromagnetic compatibility (EMC) standards and minimizing interference. This power module offers regenerative capabilities, allowing energy generated during braking to be fed back into the power supply, enhancing energy efficiency. It is designed to operate with a three-phase AC voltage supply ranging from 500 to 690V, with a tolerance of +10/-10%, and a frequency of 47-63Hz. The PM260 supports both High Overload (HO) and Light Overload (LO) operating modes, providing flexibility for various application requirements. In High Overload mode, it delivers 15kW output power with overload capabilities of 200% for 3 seconds, 150% for 57 seconds, and 100% for 240 seconds. For Light Overload applications, it provides 18.5kW output power with an overload capacity of 140% for 3 seconds and 110% continuous. This module is suitable for operation in ambient temperatures ranging from -10 to +50 degrees Celsius. The SINAMICS G120 PM260 is ideal for applications requiring precise motor control, energy efficiency, and reliable performance in demanding industrial environments.
